Reach Adjust ZS56-ZS56 - To Suit 1 1/8" Steerer - 6mm

Color: Black
$74.99

1 review
×

We often restock popular items or they may be returned by the other customers. If you would like to be notified when this happens just enter your details below.


Reach Adjust ZS56-ZS56 - To Suit 1 1/8" Steerer - 6mm

Please select variant
Please enter name
Invalid email address
Required mobile number Invalid number Invalid country code Too short Too long ✓ Valid
Your notification has been registered. Close
Looks like you already have notifications active for this size!

We respect your privacy and don't share your email with anybody.

×

We have cancelled your request.

Specifications

This headset will allow you to alter your top-tube length by +/- 6mm.

Fits headtube internal diameter: Upper - 56mm: ZS56
Fits headtube internal diameter: Lower - 56mm: ZS56

Upper cup insertion depth: 11.5mm
Lower cup insertion depth: 11.5mm

Upper cup Stack height: 3.5mm - Total upper stack height including bearing cover: 9.5mm
Lower cup Stack height: 3.5mm

Upper Bearing: 41mm OD, 45 x 45 Degree AC sealed bearing
Lower Bearing: 41mm OD, 45 x 45 Degree AC sealed bearing

To suit standard 1 1/8" forks.

What's in the Box

2x Headcups

2x Bearings

1x Crown Race

1x Upper Bearing Cover

1x Topcap including Star-Nut

1x Compression Ring and Spacer

Reach Adjust ZS56-ZS56

Change your bikes geometry to suit you - with our World Cup proven angle headsets you can alter stock geometry, changing the way your bike rides and feels to better match your personal riding style.

This Reach ZS56 ZS56 headset allows you to slacken your bikes head angle to gain more stability or steepen your bikes head angle if you are looking to sharpen your bikes steering.

This headset will allow you to alter your top-tube length by +/- 6mm.

This Reach Adjust ZS56 ZS56 fits headtube internal diameter:

Upper - 56mm
Lower - 56mm

Manufactured in the UK

All of our Angle and Reach Adjust Headsets and Chainrings are CNC machined by us in-house in the UK and supplied globally. We anodised locally in black from 6082 T6 aluminium.

We pride ourselves on the quality of everything we make to meet the highest of World Cup standards.

Used By The Best

Our Reach Adjust headsets are used by the best riders in the world.

Lou Ferguson goes through her 2024 Hardline Tasmania setup.

Show me more

Add a Custom Topcap

If bought with any of our angle or reach adjust headsets you can get a custom topcap discounted to 50% at checkout.
