1.0 Degree ZS44-ZS56 Angle Headset - To Suit Tapered Steerer Tube
Couldn't load pickup availability
Specifications
Fits headtube internal diameter: Upper - 44mm: ZS44
Fits headtube internal diameter: Lower - 56mm: ZS56
Upper cup insertion depth: 9mm
Lower cup insertion depth: 11.5mm
Upper cup Stack height: 3mm - Total upper stack height including bearing cover: 8mm
Lower cup Stack height: 3mm
Max headtube length to get a full 1.0 degree change is 126mm due to space for bearing offset internally - above this length the alternative EC44/ZS56 would be the preffered option as it allows the upper bearing to be offset externally - The ZS44/ZS56 combination is only available in the 1.0 degree option.
If you are running a 1 1/8" fork you will need to purchase the reducer crown above - this headset comes as standard with a crown race to suit tapered forks.
Description
Change your bikes geometry to suit you - with our World Cup proven angle headsets you can alter stock geometry, changing the way your bike rides and feels to better match your personal riding style. With years of experience manufacturing Angle Headsets, we continue to help riders from those just starting out to the worlds fastest racers adjust their bike to suit them - CNC machined in-house in the UK and supplied globally.The 1.0 degree ZS44 ZS56 headset allows you to slacken your bikes head angle to gain more stability or steepen your bikes head angle if you are looking to sharpen your bikes steering.
What's in the Box
2x Headcups
2x Bearings
1x Crown Race
1x Upper Bearing Cover
1x Topcap including Star-Nut
1x Compression Ring and Spacer
ZS44-ZS56
Change your bikes geometry to suit you - with our World Cup proven angle headsets you can alter stock geometry, changing the way your bike rides and feels to better match your personal riding style.
The 1.0 degree ZS44 ZS56 headset allows you to slacken your bikes head angle to gain more stability or steepen your bikes head angle if you are looking to sharpen your bikes steering.
Is the ZS44-ZS56 the right Headset for you?
Click below to see out Angle Headset buying guide!
Manufactured in the UK
All of our Angle and Reach Adjust Headsets and Chainrings are CNC machined by us in-house in the UK and supplied globally.
We pride ourselves on the quality of everything we make to meet the highest of World Cup standards.
Add a Custom Topcap
If bought with any of our angle or reach adjust headsets you can get a custom topcap discounted to 50% at checkout.
Description
When bought with any headset (Angle or Reach) it is discounted by 50% at checkout.
- Customisable Top-Cap, laser etched to order.
- Add your own text to 9 different designs and multiple colour options.
- Design 1,2 and 3 use the "Poppins" font, Design 4 uses the "Slaytanic" font. Design 5 uses "AmazDoo", Design 6 uses the "Poppins" font. Designs 7 and 8 use "Bungee" and Design 9 uses "AmazDoo".
- Made from 6082 Aluminium, Anodised in the UK - complete with stainless steel bolt and star-nut.
- Available in: Black, Blue, Red, Purple, Orange, Gold, Silver, Bronze and Turquoise.
